Y Strainer

The Honeywell FY69P Cast Iron Y Strainer is a high-performance filtration solution used in commercial, industrial, and central water supply systems. It is specifically designed to remove solid contaminants such as rust, metal particles, sealing materials, and welding residues from the fluid flow, ensuring smooth and efficient system operation.

Constructed with a grey cast iron body (PN16 flanged design) and equipped with a stainless steel double sieve, this Y strainer provides excellent durability, corrosion resistance, and long service life. The large mesh surface area (~0.50 mm) allows high dirt holding capacity while maintaining low flow resistance due to its optimized internal design.

The strainer ensures protection of downstream equipment such as pumps, valves, meters, and regulators, reducing maintenance costs and preventing premature system failure. It also features a removable sieve and drain plug, allowing easy cleaning and maintenance without dismantling the system.

Designed for flexibility, it can be installed in horizontal or vertical pipelines (recommended with the blanking plug facing downward for best performance).

Key Features

• Efficient filtration of dirt and debris

• Stainless steel double sieve for enhanced durability

• Low flow resistance design for better performance

• Large mesh area for high dirt holding capacity

• Powder-coated body (inside & outside) for corrosion protection

• Easy cleaning with removable sieve and drain plug

• Suitable for water, oil, and compressed air systems

Product Specifications

• Brand: Honeywell

• Model: FY69P

• Valve Type: Y Strainer

• Material: Cast Iron (Grey Cast Iron Body)

• Size Range: 1″ – 12″ (DN15 – DN200)

• Diameter: 2″ – 12″

• End Connection: Screwed End / Flanged End

• Pressure Rating: PN16

• Operating Temperature: Up to 80–85°C

• Media: Water, Oil, Compressed Air

• Automation Grade: Manual

• Color: Blue

• Country of Origin: India

• Availability: In Stock

Applications

• HVAC systems

• Water supply and distribution systems

• Industrial process pipelines

• Compressed air systems

• Pump and valve protection

Benefits

• Protects equipment from damage and corrosion

• Extends system lifespan

• Reduces maintenance and downtime

• Ensures smooth and efficient fluid flow

Installation Guidelines

• Install preferably in horizontal pipelines

• Keep blanking plug facing downward for effective dirt collection

• Ensure easy access for cleaning and maintenance

• Use shut-off valves for convenient servicing
