Recovery Units without Oil Separator

The VALUE VRDDF Recovery Station is an advanced and high-performance solution designed for the safe and efficient recovery of flammable and non-flammable refrigerants, including HFC, HCFC, and A2L, A2, A3 category gases. It is specifically engineered to handle modern refrigerants such as R32, R1234yf, R600a, and R290, making it ideal for today’s HVAC and refrigeration systems.

Equipped with a powerful 1 HP brushless DC motor and a 2-piston oil-less compressor, the unit delivers fast and efficient refrigerant recovery across multiple modes. It offers three operating modes—automatic, semi-automatic, and manual—allowing technicians to choose the most suitable method based on the application and working conditions.

The digital display with integrated high and low-pressure gauges ensures accurate monitoring and easy readability of system parameters. Its auto-cleaning function enhances performance and extends the life of the unit by preventing internal contamination.

Designed for ease of use, the station features a single control knob for simplified operation and includes an O.F.P. cable for connection to cylinders with overflow sensors, ensuring enhanced safety during operation.

Compact, lightweight, and durable, the VRDDF recovery station is easy to transport and comes with essential accessories, making it a complete and ready-to-use solution for professional technicians.

Key Features

• Suitable for flammable refrigerants (A2L, A2, A3)
• Powerful 1 HP brushless DC motor
• 3 recovery modes: automatic, semi-automatic, manual
• Digital display with high & low-pressure gauges
• Fast refrigerant recovery performance
• Auto-cleaning function for improved durability
• Oil-less, air-cooled 2-piston compressor
• Easy one-knob operation

Product Specifications

• Brand: VALUE
• Model: VRDDF
• Type: Refrigerant Recovery Station
• Power Supply: 230V / 50 Hz
• Motor Power: 1 HP (Brushless DC)
• Motor Speed: 3000 rpm
• Max Current: 5 A
• Noise Level: ≤ 85 dB
• Compressor: Oil-less, Air-cooled, 2-Piston Type
• Safety Shut-off: 38.5 bar / 3850 kPa (558 psi)

Refrigerant Compatibility:

• Category III: R12, R134a, R401C, R500, R1234yf, R600
• Category IV: R22, R401A, R401B, R402B, R407C, R407D, R408A, R409A, R411A, R411B, R412A, R502, R509, R290
• Category V: R402A, R404A, R407A, R407B, R410A, R507, R32

Recovery Rates:

• Category III (Gas / Liquid / Push-Pull): 0.43 / 3.6 / 7.50 kg/min
• Category IV (Gas / Liquid / Push-Pull): 0.54 / 4.0 / 8.50 kg/min
• Category V (Gas / Liquid / Push-Pull): 0.54 / 4.2 / 9.50 kg/min
• Operating Temperature: 0°C – 40°C
• Dimensions: 370 x 250 x 297 mm
• Weight: 11.0 kg

Included Accessories:

• Shoulder strap
• Filter drier
• 15 cm hose (1/4″ x 1/4″)
• O.F.P. hose
• Availability: In Stock

Applications

• Recovery of flammable refrigerants (R32, R290, etc.)
• HVAC and refrigeration servicing
• Air conditioning maintenance
• Industrial refrigeration systems

Benefits

• Safe handling of flammable refrigerants
• Faster and more efficient recovery
• Multiple operating modes for flexibility
• Easy monitoring with digital display
• Compact and portable design
